ANDYCINE X7S 7inch Ultra Brightness Screen Camera Field Monitor with HDMI/SDI Rugged CNC Aluminum Housing Monitor

stars, based on ( 3 )reviews
$369.00 piece
92items available
ANDYCINE


Andycine X7S 7inch Ultra Brightness Screen Camera Field Monitor Details



  • [3G-SDI,4KHDMI,3G-SDI and 4K HDMI I/O】 ANDYCINE X7S field monitor has 3G-SDI, 4K HDMI input and output, allowing it to not only display live signals, but also send them out to other monitors.Its SDI Input supports all SD, HD and SDI formats up to 1080p 60Hz and HDMI input supports formats up to 4K 2160p 30Hz, perfect support for almost all signals
  • [High Brightness 7ich IPS Screen] 2200nits brightness 7 inch IPS screen.The monitor offer a great visual experience even in the strong sunlight. Good performance IPS panel provide the better viewing angels.
  • [High Strength CNC aluminum housing] The aluminum housing protect the monitor from falling and scratch life. Long life durations.The monitor support DC 8.4V output via a DC couplers. Accept the power adapter and battery as power sourcre
  • [Friendly Kit] Package Include a Carrying Case, Power adapter, SDI Cable,D Tap to DC coupler. Andycine provide 1 year warranty on this item. Any quality issues may reach us at cs@andycine.com

Continuous Power
For power, there's a 12V DC input and a F970 battery plate (standard). You can also choose D28S/D54, LP-E6 or U60 battery plate to install other different types of batteries for power supply.
Note: When you turn off the monitor, you need to press the power button, and you can't pull out the power cable directly.
on camera monitor canon

Screen Size: 7" IPS

Display Colors: 16.7M (8 bit)

Resolution: 1920x1200 pixels

Dot Pitch: 0.07875 (H) x 0.07875 (W) (mm)

Aspect Ratio: 16:10

Brightness: 2200cd/m2

Contrast: 1200:1

Backlight: LED

Response Time: Ton+Toff=25ms

Viewing Angle: 80°/80°(L/R) 80°/80°(U/D)

Input: HDMI

Output: HDMI, DC 8V out

Audio: Stereo Headphone, Speaker(built-in)

HDMI Input/ Output Support Format:

480i/576i/480p/576p 1080i (60/59.94/50) 720p (60/59.94/50/30/29/25/24/23.98) 1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF) 4K UHD 3840×2160p (30/29.97/25/24/23.98 Hz), 4096×2160p (24Hz)

SDI Input/Output Support Format:

480i/576i720p(60/59.94/50/30/29/25/24/23.98)1080i(60/59.94/50)1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF)

Power Consumption: ≤18W

Input Voltage: DC7 ~24V

Unit Size: 180Lx120Hx22D (mm)

Unit Weight: 445g/475g (With F970 Battery Plate)




Brightness Histogram:
The Brightness Histogram is a quantitative tool to check the picture brightness.The feature shows the distribution of brightness in an image as graph of brightness along the horizontal axis (Left:Dark, Right:Bright)and a stack of the number of pixels at each level of brightness along the vertical axis.
Embedded Audio Monitoring:
The Audio Level Meters provide numerical indicators and headroom levels. It can generate accurate audio level displays to prevent errors during monitoring. The audio meter is green, and will turn yellow when exceeds -20dB, and turn red when exceeds -9dB.
Peaking Focus Assist:
The Peaking Filter is used to aid the camera operator in obtaining the sharpest possible picture. When activated, the internal processor will display a colored highlight on the screen where sharp edges appear. You can switch the putline color between red, green, blue according to different tone of the subject.
False Colors:
The False Colors filter is used to aid in the setting of camera exposure. As the camera Iris is adjusted, elements of the image will change color based on the luminance or brightness values. This enables proper exposure to be achieved without the use of costly, complicated external test equipment.
Exposure (zebras):
The Exposure is used to assist in exposure adjustment in the mode of Zebra Pattern. It is considered overexposed and displays the moving warning lines onto the over exposed areas. 1-100IRE adjustable.
Check Field:
Check Field is an assistant function to adjust camera color settings. Under the check field mode, you can use red, green, blue or mono pixels to generate the image, because hue and saturation can be adjusted more quickly and accurately in this environment.
Zoom In (4X, 9X, 16X):
Image magnification is HD signal in any part, an amplification for high quality close-up
Anamorphic Mode (1.3x, 2.0x, 2.0x mag, User-defined adjustment: 1.20X~2.00X):
Built-in selection of no squeeze, 1.3× or 2.0× allows you to use anamorphic lenses or adapters and see the image unsqueezed, even if your camera does not de-squeeze in camera. A 2.0× mag mode, magnifies the center of your image so you can check the focus of your scaled image.
Image Flip:
The Horizontal,Vertical and Hor&Ver of the image around flip.
Nine Grid:
Zoom one of the images to realize the full screen. You can switch the Mark color between Red, Green, Blue, White, Black according to different tone of the subject.
Pixel to Pixel:
Enable the filmmaker to check the image from the 1:1 signal source without scaling.This feature is essential for capturing optimum detail.
Center Marker & Safe Marker:
Safe Mark for View Finding and Composition (80%, 85%, 90%, 93%, 96%, 2.35:1). You can switch the Mark color between Red, Green, Blue, White and Black according to different tone of the subject.
Ratio Marker:
(4:3, 13:9, 14:9, 15:9, 16:9, 1.85:1, 2.35:1). Frame blanking zone includes 6 Levels, from 0-6 (Transparent to Black). You can switch the Mark color between red, green, blue, white and black according to different tone of the subject.
